Garrett Guide

Garrett Guide Hand-Held Metal Detector
Next-generation hand-held security. Sophisticated and simple metal detection for secondary screening.

Garrett Guide Hand-Held Metal Detector

Next-generation hand-held security. Sophisticated and simple metal detection for secondary screening.

Key Advantages

ELEGANCE AND EASE-OF-USE.

Maximal Effect, Minimal Effort: Takes the hallmark simplicity of Garrett handhelds to the next level with one-button activation, three-button full control. More features and more accessibility than ever before. Refined Construction: Features a sleek and modern aesthetic with IP 65 waterproofing and a microtextured dimpled rubber grip, all constructed to military spec drop test requirements.

HIGH SECURITY DETECTION.

7 Selectable Sensitivities: Lets you find your targets how you want, from focusing on large threats at low sensitivities to prison and clean-room level security at higher levels. Address Interference Instantly: Eliminates electromagnetic interference from other handhelds by pressing the Offset Button and negates the impact of troublesome rebar with the Reduced Sensitivity Switch.

RECHARGEABLE AND LONG-LASTING.

Eliminate Waste: Comes with rechargeable lithium-ion batteries and a 3- foot USB-A to USB-C charging cable to reduce environmental waste and save on repeated battery purchases. Powerful Batteries, More Uptime: Operates for more than 125 hours on a single charge and fully charges in only 5 hours.

FAST AND CONSISTENT SCANS.

Large Scanning Surface: 8-inch scan length means better screening coverage, reduced operator fatigue, and simplified scanning patterns for rapid security checks. Self-Calibrating Design: Eliminates manual sensitivity adjustments, ensuring consistent and reliable performance.

Quick Specs

Specs

  • Detection Frequency:

    ~55 kHz

  • Audio Frequency:

    ~2kHz

  • Dimensions:

    Length: 16″ [406.4mm]

  • Width:

    3.375″ [85.7mm]

  • Thickness:

    1.125” [28.6mm]

  • Shipping Dimensions:

    Length: 21″ [533.4mm]

  • Width:

    4″ [101.6mm]

Specs

  • Thickness:

    2″ [50.8]

  • Weight:

    1 lb [0.5Kg]

  • Voltage:

    3.8 Vdc

  • Current:

    15 mA typical

  • Battery:

    Lithium Ion 3.8V, 2.5Ahr

  • Operating Temperature:

    -4°F (-20°C) to 140°F (60°C)

  • Humidity:

    100%

  • Environmental:

    IP65 rating

Get the Full Technical File

Enter your details to download the full product technical specifications.

1

Contact info

2

Download pdf

Mobile Security Compliance

Compliance & Industry Certifications
Aligned with international standards to ensure quality, safety, and operational excellence across all solutions.
