VMI Security
Spectrum 180180
Spectrum 180180 provides good penetration for object recognition with sharpness and image quality.
Key Advantages
- Remote monitoring software
- Suspicious image reanalysis software
- Linux operating system
- Conveyor height settings
- 200kv and 320kv generator
- Inspection of medium and large volumes
Technical Specifications
| Dimensions | 8040 (L) / 3197 (W) / 2402 (H) [mm] 316.5" (L) / 125.9" (W) / 94.6" (H) |
|---|---|
| Weight | 5000Kg | 11023.11lbs (approximately) |
| Operating temperature and humidity | 0°C to 40°C / 5% to 95% (non-condensing) |
| Storage temperature and humidity | -40°C to 60°C / 5% to 95% (non-condensing) |
| Power supply | 220VAC (-15% to +10%); 50Hz/60Hz, +/-3Hz |
| Power | 2200VA |
| unnel dimensions | 1820mm (W) / 1802mm (H) 71.6" (W) / 70.9" (H) |
| Conveyor speed | 0,22m/s (adjustable) |
| Maximum load on the conveyor | 3000kg | 6613.9lbs (Evenly distributed load) |
| Standard generator | 200kV (configurable) |
Applications
- Airports
- Customs Servies
- Carriers
- Parcel services
- Transport operations
